Inner tube: NR+BR
Reinforcement layer: High tensile textile cords
Cover layer: NR+SBR
Working temperature: -20℃-80 ℃
Reference standard: HG/T2490-93
Safety factor: 3: 1
Application: Abrasion resistant tube and cover fabricated with highest quality material. Used in the transfer of dry materials & slurry and ideal for dry cement, pebble lime and other abrasive media.
| I.D. | O.D. | W.P. | B.P. | Tube Thickness | Weight | Length | |||
| mm | inch | mm | psi | bar | psi | bar | mm | Kg/m | m |
| 51 | 2" | 67.4 | 150 | 10 | 450 | 30 | 4.0 | 1.73 | 61 |
| 64 | 2 1/2" | 81.4 | 150 | 10 | 450 | 30 | 4.0 | 2.40 | 61 |
| 76 | 3" | 95.8 | 150 | 10 | 450 | 30 | 5.0 | 3.18 | 61 |
| 102 | 4" | 124.6 | 150 | 10 | 450 | 30 | 5.0 | 4.26 | 61 |
| 127 | 5" | 151.2 | 150 | 10 | 450 | 30 | 5.0 | 5.55 | 30.5 |
| 152 | 6" | 178.6 | 150 | 10 | 450 | 30 | 6.0 | 7.27 | 30.5 |
| Note: It can be customized according to customer requirements | |||||||||
